Description
MT-MT connector for QSFP module
Features:
8-12 core fiber available
small in size ,easy to management
loss mode: Low loss；Standard Loss
Different in fiber connection according to QSFP requirement
Manufacturer of MT:US Conec or SENKO Optional
Applications:
QSFP module
Data Center
Specifications:
| Fiber type | single mode | multimode | |
| Standard insertion loss | typical（dB） | 0.35 | 0.35 |
| Maximum（dB） | 0.75 | 0.60 | |
| Low insertion loss | typical（dB） | 0.20 | 0.20 |
| Maximum（dB） | 0.35 | 0.35 | |
| Return loss （dB） | ≥60（APC） | ≥20（PC） | |
| ≥50（PC） | |||
| Tensile Strength (kgf ) | 10 | ||
| Durability （dB） | ≤0.2 500 matings | ||
| working temperature （℃） | －40 ～+85 | ||
| Test wavelength （nm） | 1310 | 850 | |
